3031270 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

3031270
Manufacturer

Phoenix
ChipWorker Part#

CW38544675
Category

Terminal Block, Connector Terminal
Description

Conn; Term Blk; 2; 4; 28-12AWG; Gray; 2; 4; PA; 67.5mm L x 5.2mm W x 47.5mm H
Documentation

Datasheet

3031270 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

3031270 Specifications

Attribute	Attribute Value

Part Number	3031270
Manufacturer	Phoenix
ChipWorker Part#	CW38544675
Category	Terminal Block, Connector Terminal
Documentation	Datasheet
Mounting Style	DIN Rail
Pin Pitch	4.2 mm
Number of Contacts	4 Contact
Wire Gauge	12AWG ~ 28AWG
Voltage Rating (DC)	500 V
Current Rating	22 A
Number of Rows	4 Row
Number of Circuits	1 Circuit
Flammability Rating	UL 94 V-0
Number of Positions	4 Position
Current Rating (Max)	26 A
Operating Temperature (Max)	110 ℃
Operating Temperature (Min)	-50 ℃
Voltage Rating (Max)	500 V
Voltage Rating	500 V
Operating Voltage (Max)	500 V
	expand all
Size-Length	67.5 mm
Size-Width	5.2 mm
Size-Height	55 mm
Housing Color	Gray
Color	Gray
Insulation Material	Nylon
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HTS Code	8536904000
ECCN Code	EAR99

Product Description

Terminal Block with Spring-Cage Connection, PA Insulating Material
* PA insulation material
Gray color, spring-cage connection type.
