AD5060 Specifications

Attribute	Attribute Value

Part Number	AD5060
Manufacturer	ADI
ChipWorker Part#	CW430812713
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active

Product Description

Product Details
The AD5060, a member of the _nano_DAC® family, is a single, full accurate 16-bit buffered voltage out DAC in a SOT-23.
By combining a 16-bit DAC and high performance output buffer in a SOT-23, the AD5060 delivers a maximum 1 LSB INL linearity error, making it ideal for high performance applications such as open loop control or precision gain and offset. The part utilizes a versatile three-wire serial interface that operates at clock rates up to 30 MHz and is compatible with standard SPI™, QSPI™, MICROWIRE™ and DSP interface standards. The reference for the AD5060 is supplied from an external REF pin with a reference buffer provided on chip to simplify application of the device. The part incorporates a power-on-reset circuit that depending on model ensures the DAC output powers up to zero volts/mid scale and remains there until a valid write takes place to the device. The part also contains a power-down feature that reduces the current consumption of the device to 1 µA at 5 V and provides software selectable output loads while in power-down mode. Power-down mode is activated over the serial interface with very low glitch on power up. Total unadjusted error for the part is <1 mV.
**Product Highlights**
1. Available in 8-lead SOT23.
2. 16 Bit Accurate, MAX 1 LSB INL including output buffer
3. Low Glitch on Power-up.
4. High speed serial interface with clock speeds up to 30 MHz.
5. Three power down modes available to the user.
**Applications**
Process Control
Data Acquisition Systems
Portable Battery Powered Instruments
Digital Gain and Offset Adjustment
Programmable Voltage and Current Sources
Programmable Attenuators
### Features and Benefits
Available in 8-lead SOT23
16 Bit Accurate, MAX 1 LSB INL including output buffer
Low Glitch on Power-up
Three power down functions available
High speed serial interface with clock speeds up to 30 MHz
Three power down modes available to the user
