AD7940BRM - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD7940BRM
Manufacturer

ADI
ChipWorker Part#

CW50345933
Category

Analog to Digital, ADC IC
Package

MSOP-8
Description

ANALOG DEVICES AD7940BRM Analogue to Digital Converter, 14Bit, 100KSPS, Single, 2.5V, 5.5V, MSOP
Documentation

Datasheet

AD7940BRM Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD7940BRM Specifications

Attribute	Attribute Value

Part Number	AD7940BRM
Manufacturer	ADI
ChipWorker Part#	CW50345933
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Digital Logic Level	SAR
Supply Voltage (DC)	2.50V (min)
Supply Current	5.2 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Number of Bits	14 Bit
Power Dissipation	26.4 W
Sample Rate	100 ksps
Resolution (Bits)	14.0 Bit
Input Capacitance	30.0 pF
Number of ADCs	1 ADC
Number of Inputs	1 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	26.4 mW
Number of Input Channels	1 Channel
Supply Voltage	2.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.5 V
Input Voltage	5.5 V
	expand all
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	End of Life
Packaging	Each
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17

Product Description

14 Bit Analog to Digital Converter 1 Input 1 SAR 8-MSOP
