AD847ARZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD847ARZ
Manufacturer

ADI
ChipWorker Part#

CW3272868
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

ANALOG DEVICES AD847ARZ Operational Amplifier, Single, 1 Amplifier, 50MHz, 300V/µs, ± 4.5V to ± 18V, SOIC, 8Pins
Documentation

Datasheet

AD847ARZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD847ARZ Specifications

Attribute	Attribute Value

Part Number	AD847ARZ
Manufacturer	ADI
ChipWorker Part#	CW3272868
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	5.3 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	0.8 W
Common Mode Rejection Ratio	78 dB
Input Capacitance	1.50 pF
Bandwidth	50 MHz
Slew Rate	300 V/μs
Gain Bandwidth Product	35 MHz
Input Impedance	300 kΩ
Input Offset Voltage	500 µV
Input Bias Current	3.3 µA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	50 MHz
Power Dissipation (Max)	800 mW
Minimum CMRR Range	78 dB
Supply Voltage (Max)	18 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The AD847ARZ is a low power monolithic Operational Amplifier for use with high speed cable driver. The AD847 represents a breakthrough in high speed amplifier offering superior AC and DC performance and low power. The excellent DC performance is demonstrated by its ±5V specifications which include an open-loop gain of 3500V/V (500R load) and low input offset voltage of 0.5mV. Common-mode rejection is a minimum of 78dB. Output voltage swing is ±3V into loads as low as 150R.
Excellent DC performance
Drives any capacitive load
5.3mA Low supply current
65ns Fast settling time to 0.1% (10V step)
5.5V/mV (RL=1kR) High open-loop gain
0.5mV Low input offset voltage
ESD sensitive device, electrostatic charges as high as 4000V readily accumulate on the human body and test equipment and can discharge without detection.
