CW92158
Category

Interface IC, Interface Controller
Package

SOIC-8
Description

ANALOG DEVICES ADM3485EARZ ESD Protected, EMC Compliant, 3.3V, 20Mbps, EIA RS485 Transceiver, SOIC-8
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.43

Buy ADM3485EARZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADM3485EARZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADM3485EARZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADM3485EARZ
Manufacturer	ADI
ChipWorker Part#	CW92158
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.30V (max)
Supply Current	2.2 mA
Number of Positions	8 Position
Data Rate	15.0 Mbps
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The ADM3485EARZ is a Low Power Half-duplex RS-485/RS-422 Transceiver that operates from a single 3.3V power supply. Low power consumption, coupled with a shutdown mode makes it ideal for power-sensitive applications. It transmits at up to 10Mbps. The receiver input impedance is 12kR, allowing up to 32 transceivers to be connected on the bus. A thermal shutdown circuit prevents excessive power dissipation caused by bus contention or by output shorting. If a significant temperature increase is detected in the internal driver circuitry during fault conditions, then the thermal shutdown circuit forces the driver output into a high impedance state. If the inputs are unconnected (floating), the receiver contains a fail-safe feature that results in a logic high output state.
Interoperable with 5V logic
10Mbps Data rate
2nA Supply current in shutdown mode
Up to 32 transceivers on the bus
-7 to +12V Bus common-mode range
8ns Skew
ESD sensitive device, take proper precaution while handling the device.
