ADN4665 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADN4665
Manufacturer

ADI
ChipWorker Part#

CW353139675
RoHS

Lead free / RoHS Compliant
Description

3V, LVDS, Quad, CMOS Differential Line Driver
Documentation

Datasheet

ADN4665 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADN4665 Specifications

Attribute	Attribute Value

Part Number	ADN4665
Manufacturer	ADI
ChipWorker Part#	CW353139675
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant

Product Description

Product Details
The ADN4665 is a quad-channel, CMOS, low voltage differential signaling (LVDS) line driver offering data rates of over 400 Mbps (200 MHz) and ultralow power consumption.
The device accepts low voltage TTL/CMOS logic signals and converts them to a differential current output of typically ±3.5 mA for driving a transmission medium such as a twisted pair cable. The transmitted signal develops a differential voltage of typi-cally ±350 mV across a termination resistor at the receiving end. This voltage is converted back to a TTL/CMOS logic level by an LVDS receiver.
The ADN4665 also offers active high and active low enable/ disable inputs (EN and overbar: EN). These inputs control all four drivers and turn off the current outputs in the disabled state to reduce the quiescent power consumption to typically 10 mW. The ADN4665 offers a new solution to high speed, point-to-point data transmission and offers a low power alternative to emitter-coupled logic (ECL) or positive emitter-coupled logic (PECL).
**Applications**
* Backplane data transmission
* Cable data transmission
* Clock distribution
### Features and Benefits
±15 kV ESD protection on output pins
400 Mbps (200 MHz) switching rates
100 ps typical differential skew
400 ps maximum differential skew
2 ns maximum propagation delay
3.3 V power supply
|
±350 mV differential signaling
Low power dissipation (13 mW typical)
Interoperable with existing 5 V LVDS receivers
High impedance on LVDS outputs on power-down
Conforms to TIA/EIA-644 LVDS standards
See data sheet for additional features
---|---
