ADS62C17EVM ,Microprocessor Development Kit - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

70 points

Part No

ADS62C17EVM
Manufacturer

TI
ChipWorker Part#

CW72051641
Category

Microprocessor Development Kit
Description

TEXAS INSTRUMENTS ADS62C17EVM Evaluation Board, 11Bit 200M Samples per Second Analog to Digital Converter
Documentation

Datasheet
Ships from

Moscow
Наличие

1 pcs In Stock
Estimated Price

$ 307.85

Buy ADS62C17EVM

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADS62C17EVM Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADS62C17EVM Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADS62C17EVM
Manufacturer	TI
ChipWorker Part#	CW72051641
Category	Microprocessor Development Kit
Documentation	Datasheet
Number of Bits	11 Bit
Sample Rate	200 Msps
Number of ADCs	2 ADC
	expand all
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	3A991.c.1

Similar & Replacement Parts

Similar products

Product Description

The ADS62C17EVM is a circuit board that allows designers to evaluate the performance of Texas Instruments" ADS62C17 device, a dual channel 11-bit 200 MSPS analog to digital converter featuring TI"s SNRBoost technology. The ADC features a user selectable parallel CMOS or DDR LVDS output. Users can use either the TSW1100 (CMOS mode) or TSW1400EVM or TSW1405EVM(DDR LVDS mode) to capture the data from the converter. The EVM provides a flexible environment to test the ADS62C17 under a variety of clock, input and supply conditions.
The ADS62C17EVM also includes an open socket for Texas Instrument’s new 10 Output Low Jitter Clock Synchronizer and Jitter Cleaner device, the CDCE72010, which can be used to drive the clocking input to the ADS62C17. Open sockets are also provided for an external VCXO and crystal band pass filter allowing for rapid evaluation of a combined high performance ADC and clocking circuit equivalent to a final system level solution. Alternatively an external clock source can be provided to the EVM and either routed through the CDCE72010 or passed directly to the ADS62C17 clock input. By default, the EVM is designed for an external clock source to directly clock the ADS62C17.
The evaluation module also allows designers to use either a transformer coupled input into the ADC or an amplifier input based on the Texas Instruments" THS4509. While the ADC EVM comes with the THS4509, users can easily evaluate any of the footprint compatible ADC driving amplifiers such as the THS4508, THS4511 and THS4520.
