Part No

BAT43
Manufacturer

ST Microelectronics
ChipWorker Part#

CW2035896
Category

Schottky Diode
Package

DO-35
Description

STMICROELECTRONICS BAT43 Small Signal Schottky Diode, Single, 30V, 200mA, 1V, 4A, 125℃
Documentation

Datasheet
Ships from

Moscow
Наличие

2430 pcs In Stock
Estimated Price

$ 0.1

Buy BAT43

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

BAT43 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

BAT43 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	BAT43
Manufacturer	ST Microelectronics
ChipWorker Part#	CW2035896
Category	Schottky Diode
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	DO-35
Voltage Rating (DC)	30.0 V
Current Rating	200 mA
Capacitance	7.00 pF
Output Current	≤200 mA
Load Current	0.2 A
Number of Positions	2 Position
Forward Voltage	1V @200mA
Polarity	Standard
Power Dissipation	200 mW
Thermal Resistance	300℃/W (RθJA)
Reverse recovery time	5 ns
Forward Current	200 mA
Max Forward Surge Current (Ifsm)	4 A
Maximum Forward Voltage (Max)	450 mV
Forward Current (Max)	200 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature (Max)	150 ℃
Power Dissipation (Max)	200 mW
	expand all
Size-Length	4.5 mm
Size-Width	2 mm
Size-Height	2 mm
Operating Temperature	-65℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The BAT43 is a general purpose, metal to silicon small signal Schottky Diode featuring very low turn-on voltage fast switching. This device have integrated protection against excessive voltage such as electrostatic discharge.
