BZX84C13LT1G Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | BZX84C13LT1G |
| Manufacturer | ON Semiconductor |
| ChipWorker Part# | CW2115433 |
| Category | Zener Diode, Zener |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-23-3 |
| Voltage Rating (DC) | 13.0 V |
| Capacitance Tolerance | ±6 % |
| Power Rating | 225 mW |
| Halogen Free Status | Halogen Free |
| Number of Positions | 3 Position |
| Forward Voltage | 900mV @10mA |
| Power Dissipation | 225 mW |
| Test Current | 5 mA |
| Forward Current | 10 mA |
| Zener Voltage | 13 V |
| Maximum Forward Voltage (Max) | 900mV @10mA |
| Input Power (Max) | 225 mW |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -65 ℃ |
| Junction Temperature (Max) | 150 ℃ |
| Power Dissipation (Max) | 300 mW |
| expand all | |
| Size-Length | 3.04 mm |
| Size-Width | 1.3 mm |
| Size-Height | 0.94 mm |
| Material | Plastic |
| Operating Temperature | -65℃ ~ 150℃ |
| Temperature Coefficient | 9 mV/K |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
Product Description
- The BZX84CxxxLT1G series surface mount Zener Diode designed to provide voltage regulation with minimum space requirement. They are well suited for applications such as cellular phones, hand held portables and high density PC boards.
- 225mW Rating on FR-4 or FR-5 board
- Small package size for high density applications
- Tight tolerance available
- ESD rating of Class 3 (>16kV) per human body model
- AEC-Q101 qualified and PPAP capable
- Pb-free device
