CD4069UBEE4 ,Logic Control, Logic Gate IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

84 points

Part No

CD4069UBEE4
Manufacturer

TI
ChipWorker Part#

CW86508496
Category

Logic Control, Logic Gate IC
Package

PDIP-14
Description

TEXAS INSTRUMENTS CD4069UBEE4 Inverter, CD4069, 1Input, 6.8mA, 3V to 18V, DIP-14
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.11

Buy CD4069UBEE4

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

CD4069UBEE4 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

CD4069UBEE4 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	CD4069UBEE4
Manufacturer	TI
ChipWorker Part#	CW86508496
Category	Logic Control, Logic Gate IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	14 Pin
Case/Package	PDIP-14
Supply Voltage (DC)	3.00V (min)
Output Current	6.8 mA
Number of Circuits	6 Circuit
Number of Bits	6 Bit
Propagation Delay Max (tpd)	110 ns
Voltage Nodes	5.00 V, 10.0 V, 15.0 V
Number of Inputs	6 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	3V ~ 18V
Supply Voltage (Max)	18 V
Supply Voltage (Min)	3 V
	expand all
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

3 Description
The CD4069UB device consist of six CMOS inverter circuits. These devices are intended for all general purpose inverter applications where the medium power TTL-drive and logic-level-conversion capabilities of circuits such as the CD4009 and CD4049 hex inverter and buffers are not required.
Features
• Standardized Symmetrical Output Characteristics
• Medium Speed Operation: –tPHL, tPLH = 30 ns at 10 V (Typical)
• 100% Tested for Quiescent Current at 20 V
• Maximum Input Current of 1 µA at 18 V Over Full Package-Temperature Range, 100 nA at 18 V and 25°C
• Meets All Requirements of JEDEC Tentative Standard No. 13B, Standard Specifications for Description of B Series CMOS Devices
Applications
• Logic Inversion
• Pulse Shaping
• Oscillators
• High-Input-Impedance Amplifiers
