CD74HCT112E ,Flip Flop IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

129 points

Part No

CD74HCT112E
Manufacturer

TI
ChipWorker Part#

CW8189336
Category

Flip Flop IC
Package

DIP-16
Description

Flip Flop JK-Type Neg-Edge 2Element 16Pin PDIP Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

779 pcs In Stock
Estimated Price

$ 0.22

Buy CD74HCT112E

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

CD74HCT112E Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

CD74HCT112E Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	CD74HCT112E
Manufacturer	TI
ChipWorker Part#	CW8189336
Category	Flip Flop IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Frequency	60 MHz
Supply Voltage (DC)	5.00 V, 5.50 V (max)
Number of Outputs	1 Output
Output Current	4 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	16 Position
Clock Speed	60 MHz
Number of Bits	2 Bit
Polarity	Non-Inverting, Inverting
Input Capacitance	10 pF
Number of Inputs	2 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	19.3 mm
Size-Width	6.35 mm
Size-Height	4.57 mm
Operating Temperature	-55℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The CD74HCT112E is a dual negative-edge-triggered J-K Flip-flop with set and reset. It utilizes silicon-gate CMOS technology to achieve operating speeds equivalent to LSTTL parts. It exhibits the low power consumption of standard CMOS integrated circuits, together with the ability to drive 10 LSTTL loads. It has independent J, K, Set, Reset and Clock inputs and Q and Q\ outputs. It changes state on the negative-going transition of the clock pulse. Set and Reset are accomplished asynchronously by low-level inputs. The HCT logic family is functionally as well as pin-compatible with the standard LS logic family.
Hysteresis on clock inputs for improved noise immunity and increased input rise and fall times
Asynchronous reset
Complementary outputs
Buffered inputs
Balanced propagation delay and transition times
Significant power reduction compared to LSTTL logic ICs
High noise immunity
Direct LSTTL input logic compatibility
CMOS Input compatibility
15 LSTTL Load bus driver outputs
