CSD19531KCS - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

CSD19531KCS
Manufacturer

TI
ChipWorker Part#

CW2893708
Category

MOSFET, MOSFET Transistor
Package

TO-220-3
Description

TO-220 N-CH 100V 100A
Documentation

Datasheet

CSD19531KCS Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

CSD19531KCS Specifications

Attribute	Attribute Value

Part Number	CSD19531KCS
Manufacturer	TI
ChipWorker Part#	CW2893708
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.0064 Ω
Polarity	N-Channel
Power Dissipation	179 W
Threshold Voltage	2.7 V
Drain to Source Voltage (Vds)	100 V
Continuous Drain Current (Ids)	100A
Rise Time	7.2 ns
Input Capacitance (Ciss)	3870pF @50V(Vds)
Input Power (Max)	214 W
Fall Time	4.1 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	214W (Tc)
	expand all
Size-Length	10.67 mm
Size-Width	4.7 mm
Size-Height	16.51 mm
Material	Silicon
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The CSD19531KCS is a NexFET™ N-channel Power MOSFET designed to minimize losses in power conversion applications It is suitable for use in secondary-side synchronous rectifier and hot-swap telecom applications.
Ultra-low Qg and Qgd
Low thermal resistance
Avalanche rated
Halogen-free
Plastic package
-55 to 175°C Operating junction temperature range
