DR24D12 - Crydom

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

DR24D12
Manufacturer

Crydom
ChipWorker Part#

CW11627200
Category

Solid State Relay
Package

Module
Description

Relay SSR 11mA 32V DC-IN 12A 280V AC-OUT 4Pin
Documentation

Datasheet

DR24D12 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

DR24D12 Specifications

Attribute	Attribute Value

Part Number	DR24D12
Manufacturer	Crydom
ChipWorker Part#	CW11627200
Category	Solid State Relay
Documentation	Datasheet
Mounting Style	Screw
Number of Pins	4 Pin
Case/Package	Module
Current Rating	12 A
Output Voltage	24V ~ 280V
Load Current	12 A
Input Current	9mA ~ 11mA
Isolation Voltage	4000 v
Input Voltage (Max)	32 V
Input Voltage (Min)	4 V
Output Voltage (Max)	280 V
Input Current (Min)	11 mA
Load Current (Max)	12 Arms
Load Current (Min)	150 mArms
Operating Temperature (Max)	80 ℃
Operating Temperature (Min)	-30 ℃
Voltage Rating	280 VAC
Operating Voltage (Min)	24 VAC
Operating Voltage (Max)	280 VAC
Input Voltage	4VDC ~ 32VDC
	expand all
Size-Length	83.7 mm
Size-Height	90.3 mm
Operating Temperature	-30℃ ~ 80℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
HTS Code	8536490080
ECCN Code	EAR99

Product Description

* 6 & 12 Amps output power rating
* 60 & 100 VDC, 24 to 600 VAC operating voltage ratings
* 4-32 VDC, 24, 120 & 230 VAC control input options available
* IP20 housing with unique integrated heat sink design (Patent Pending)
* AC Output versions with Zero Voltage Turn-On for resistive loads and Random Turn-On for inductive loads
* High power density for multiple units
* UL & cUL approved including General Purpose and Motor Controller ratings
* CE & RoHS compliant
