ESDA5V3SC5 Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | ESDA5V3SC5 | |
| Manufacturer | ST Microelectronics | |
| ChipWorker Part# | CW8040331 | |
| Category | TVS Diode | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 5 Pin | |
| Case/Package | SOT-23-5 | |
| Voltage Rating (DC) | 5.30 V | |
| Operating Voltage | 5.3 V | |
| Capacitance | 280 pF | |
| Power Rating | 500 W | |
| Breakdown Voltage | 5.9 V | |
| Number of Circuits | 4 Circuit | |
| Number of Positions | 5 Position | |
| Test Current | 1 mA | |
| Peak Pulse Power | 500 W | |
| Min Breakdown Voltage | 5.3 V | |
| Reverse Breakdown Voltage | 5.3 V | |
| Operating Temperature (Max) | 125 ℃ | |
| Operating Temperature (Min) | -40 ℃ | |
| expand all | ||
| Size-Length | 3 mm | |
| Size-Width | 1.75 mm | |
| Size-Height | 1.3 mm | |
| Operating Temperature | -40℃ ~ 125℃ (TA) | |
| Product Lifecycle Status | Active | |
| Packaging | Tape & Reel (TR) | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| REACH SVHC Compliance Edition | 2015/12/17 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- The ESDA5V3SC5 is a Quad Transil™ ESD Protection Device Array designed to protect components which are connected to data and transmission lines against ESD. They clamp the voltage just above the logic level supply for positive transients and to a diode drop below ground for negative transient.
- 4 Unidirectional ESD protection
- 400W at 8/20µs Peak pulse power
- High ESD protection level up to 30kV
- High integration
- Suitable for high density boards
- -55 to 150°C Operating junction temperature range
