FOD817A3SD ,Optocoupler, Optoisolator - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

148 points

Part No

FOD817A3SD
Manufacturer

Fairchild
ChipWorker Part#

CW7943763
Category

Optocoupler, Optoisolator
Package

SMD-4
Description

The FOD817 is a 4Pin DIP Phototransistor Output Optocoupler The FOD814 consists of two gallium arsenide infrared emitting diodes, connected in inverse parallel, driving a silicon phototransistor output in a 4Pin dual in-line package. The FOD817 Series consists of a gallium arsenide infrared emitting diode driving a silicon phototransistor in a 4Pin dual in-line package.
