HEF4049BT - Nexperia

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

HEF4049BT
Manufacturer

Nexperia
ChipWorker Part#

CW3776504
Package

SOIC-16
Description

Buffer/Converter 6CH Inverting CMOS 16Pin SO
Documentation

Datasheet

HEF4049BT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HEF4049BT Specifications

Attribute	Attribute Value

Part Number	HEF4049BT
Manufacturer	Nexperia
ChipWorker Part#	CW3776504
Documentation	Datasheet
Number of Pins	16 Pin
Case/Package	SOIC-16
Number of Positions	16 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	15.5 V
Supply Voltage (Min)	4.5 V
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant

Product Description

The HEF4049BT is a Hex Inverting Buffer with high current output capability suitable for driving TTL or high capacitive loads. Since input voltages in excess of the buffer supply voltage are permitted, the buffers may also be used to convert logic levels of up to 15V to standard TTL levels. It is guaranteed fan-out into common bipolar logic elements. It operates over a recommended VDD power supply range of 3 to 15V referenced to VSS. Unused inputs must be connected to VDD, VSS or another input.
Accepts input voltages in excess of the supply voltage
Fully static operation
Standardized symmetrical output characteristics
5, 10 and 15V Parametric ratings
Complies with JEDEC standard JESD 13-B
