HMC516 ,Amplifier chip - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

88 points

Part No

HMC516
Manufacturer

ADI
ChipWorker Part#

CW2341375
Category

Amplifier chip
Package

Die
Description

ANALOG DEVICES HMC516 RF Amplifier IC, 20.5dB Gain / 1.8dB Noise, 7GHz to 17GHz, 2.5V to 3.5V, Gel Pack
Documentation

Datasheet
Ships from

Moscow
Наличие

868 pcs In Stock
Estimated Price

$ 23.13

Buy HMC516

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

HMC516 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

HMC516 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	HMC516
Manufacturer	ADI
ChipWorker Part#	CW2341375
Category	Amplifier chip
Documentation	Datasheet
Number of Pins	8 Pin
Case/Package	Die
Frequency	7GHz ~ 17GHz
Supply Voltage (DC)	2.50V (min)
Supply Current	65 mA
Number of Channels	1 Channel
Power Dissipation	1.25 W
Gain	20.5 dB
Test Frequency	7GHz ~ 17GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1250 mW
Supply Voltage	3 V
Supply Voltage (Max)	3.5 V
Supply Voltage (Min)	2.5 V
	expand all
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

Product Details
The HMC516 chip is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier (LNA) which covers the 7 to 17 GHz frequency range. The HMC516 provides 20 dB of small signal gain, 1.8 dB of noise figure and has an output IP3 greater than +20 dBm. The chip can easily be integrated into hybrid or MCM assemblies due to its small size. All data is tested with the chip in a 50 Ohm test fixture connected via 0.075mm (3 mil) ribbon bonds of minimal length 0.31 mm (12 mil). Two 0.025 mm (1 mil) diameter bondwires may also be used to make the RFIN and RFOUT connections.
Applications
Point-to-Point Radios
Point-to-Multi-Point Radios & VSAT
Test Equipment and Sensors
Military & Space
### Features and Benefits
Noise Figure: 1.8 dB
Gain: 20 dB
OIP3: +20 dBm
Single Supply: 3V @ 65 mA
50 Ohm Matched Input/Output
Die Size: 2.52 x 1.32 x 0.1 mm
