IPZ40N04S5L2R8ATMA1 - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IPZ40N04S5L2R8ATMA1
Manufacturer

Infineon
ChipWorker Part#

CW37618874
Category

MOSFET, MOSFET Transistor
Package

PG-TSDSON-8
Description

TSDSON N-CH 40V 40A
Documentation

Datasheet

IPZ40N04S5L2R8ATMA1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IPZ40N04S5L2R8ATMA1 Specifications

Attribute	Attribute Value

Part Number	IPZ40N04S5L2R8ATMA1
Manufacturer	Infineon
ChipWorker Part#	CW37618874
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	PG-TSDSON-8
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.0022 Ω
Polarity	N-CH
Power Dissipation	71 W
Threshold Voltage	1.6 V
Drain to Source Voltage (Vds)	40 V
Continuous Drain Current (Ids)	40A
Rise Time	3 ns
Input Capacitance (Ciss)	2800pF @25V(Vds)
Fall Time	14 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	71W (Tc)
	expand all
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Compliant with Exemption
Lead-Free Status

Product Description

Summary of Features:
OptiMOS™ - power MOSFET for automotive applications
N-channel - Enhancement mode - Logic Level
AEC Q101 qualified
MSL1 up to 260°C peak reflow
175°C operating temperature
Green Product (RoHS compliant)
100% Avalanche tested
Simulation/ SPICE-Model
