IR2117STRPBF - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IR2117STRPBF
Manufacturer

Infineon
ChipWorker Part#

CW7161503
Category

FET Driver
Package

SOIC-8
Description

MOSFET DRVR 600V 0.5A 1Out Hi/Lo Side Non-Inv 8Pin SOIC T/R
Documentation

Datasheet

IR2117STRPBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IR2117STRPBF Specifications

Attribute	Attribute Value

Part Number	IR2117STRPBF
Manufacturer	Infineon
ChipWorker Part#	CW7161503
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Operating Voltage	10V ~ 20V
Rise/Fall Time	80ns, 40ns
Number of Outputs	1 Output
Number of Positions	8 Position
Power Dissipation	625 mW
Quiescent Current	340 µA
Rise Time	130 ns
Fall Time	65 ns
Fall Time (Max)	65 ns
Fall Time (Max)	130 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	625 mW
Supply Voltage	10V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	10 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

Summary of Features:
Floating channel designed for bootstrap operation
Fully operational to +600 V
Tolerant to negative transient voltage
dV/dt immune
Gate drive supply range from 10 to 20 V
Undervoltage lockout
CMOS Schmitt-triggered inputs with pull-down
Output in phase with input (IR2117) or out of phase with input (IR2118 )
