LMZ12003TZE-ADJ/NOPB ,DC to DC Converter - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

112 points

Part No

LMZ12003TZE-ADJ/NOPB
Manufacturer

TI
ChipWorker Part#

CW24741445
Category

DC to DC Converter
Package

TO-PMOD-7
Description

Module DC-DC 1Out 0.8V to 6V 3A 7Pin TO-PMOD EP
Documentation

Datasheet
Ships from

Moscow
Наличие

306 pcs In Stock
Estimated Price

$ 13.43

Buy LMZ12003TZE-ADJ/NOPB

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LMZ12003TZE-ADJ/NOPB Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LMZ12003TZE-ADJ/NOPB Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LMZ12003TZE-ADJ/NOPB
Manufacturer	TI
ChipWorker Part#	CW24741445
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	7 Pin
Case/Package	TO-PMOD-7
Power Rating	18 W
Number of Outputs	1 Output
Output Voltage	0.8V ~ 6V
Output Current	3 A
Number of Positions	7 Position
Quiescent Current	1.00 mA
Number of Regulated Outputs	1 Output
Switching Frequency	1 MHz
Topology	Buck
Input Voltage (Max)	20 V
Input Voltage (Min)	4.5 V
Output Voltage (Max)	6 V
Output Voltage (Min)	800 mV
Output Current (Max)	3 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	4.5V ~ 20V
	expand all
Size-Length	10.16 mm
Size-Width	9.85 mm
Size-Height	4.53 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The LMZ12003TZE-ADJ/NOPB is a SIMPLE SWITCHER® Power Module with 20V maximum input voltage. The power module is an easy-to-use step-down DC-DC solution capable of driving up to 3-A load with exceptional power conversion efficiency, line and load regulation and output accuracy. It enhances thermal performance and allows for hand or machine soldering. The LMZ12003 can accept an input voltage rail between 4.5 and 20V and can deliver an adjustable and highly accurate output voltage as low as 0.8V. The LMZ12003 only requires three external resistors and four external capacitors to complete the power solution. The LMZ12003 is a reliable and robust design with the following protection features thermal shutdown, input undervoltage lockout, output overvoltage protection, short circuit protection, output current limit and this device allows start-up into a pre-biased output. A single resistor adjusts the switching frequency up to 1MHz.
Integrated shielded inductor
Simple PCB layout
Flexible start-up sequencing using external soft-start capacitor and precision enable
Protection against inrush currents and faults such as input UVLO and output short circuit
Single exposed pad and standard pinout for easy mounting and manufacturing
Fast transient response for FPGAs and ASICs
Low output voltage ripple
Fully WEBENCH® Power designer enabled
Operates at high ambient temperature with no thermal derating
High efficiency reduces system heat generation
18W Total power output
92% Efficiency
Low radiated emissions (EMI) tested to EN55022 class B standard
Green product and no Sb/Br
