LQH66SN100M03L ,Inductor Surface Mount - muRata
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
149 points
-
Part NoLQH66SN100M03L
-
ManufacturermuRata
-
ChipWorker Part#CW9274326
-
CategoryInductor Surface Mount
-
Package2525
-
Description2525 10uH ±20%
-
DocumentationDatasheet
-
Ships fromMoscow
-
НаличиеIn Stock
-
Estimated Price$ 0.7
