MC34063AP ,DC to DC Converter - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

136 points

Part No

MC34063AP
Manufacturer

TI
ChipWorker Part#

CW2971687
Category

DC to DC Converter
Package

DIP-8
Description

Conv DC-DC 3V to 40V Inv/Step Up/Step Down Single-Out 1.25V to 40V 1.5A 8Pin PDIP Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.78

Buy MC34063AP

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MC34063AP Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MC34063AP Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MC34063AP
Manufacturer	TI
ChipWorker Part#	CW2971687
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Frequency	100 kHz
Supply Voltage (DC)	40.0V (max)
Number of Outputs	1 Output
Input Voltage (DC)	40.0 V
Output Voltage	1.25V ~ 40V
Output Current	1.5 A
Number of Positions	8 Position
Input Current	4 mA
Quiescent Current	4.00 mA
Number of Regulated Outputs	1 Output
Switching Frequency	100 kHz
Topology	Buck, Boost
Input Voltage (Max)	40 V
Input Voltage (Min)	3 V
Output Voltage (Max)	40 V
Output Voltage (Min)	1.25 V
Output Current (Max)	1.5 A
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	3V ~ 40V
Supply Voltage (Min)	3 V
Input Voltage	3V ~ 40V
	expand all
Size-Length	9.81 mm
Size-Width	6.35 mm
Size-Height	4.57 mm
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
HK STC License	NLR

Similar & Replacement Parts

Similar products

Product Description

The MC34063AP is a boost/buck/inverting switching regulator in 8 pin DIP package. It is an easy to use regulator containing all primary circuitry needed for building simple DC to DC converters. The MC34063AP regulator primarily consist of an internal temperature compensated reference, comparator, oscillator, PWM controller with active current limiting, driver and high current output switch. This device requires minimal external components to build converters in boost, buck and inverting topologies.
Adjustable output voltage range from 1.25V to 40V
Wide input voltage range from 3V to 40V
High output switch current up to 1.5A
Oscillator frequency up to 100KHz
Precision internal reference is 2%
Short circuit current limiting
Low standby current
Operating temperature range 0°C to 70°C
