MPSA13G ,BJT Transistor, BJT - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

72 points

Part No

MPSA13G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW79238793
Category

BJT Transistor, BJT
Package

TO-226-3
Description

TO-92 NPN 30V 0.5A
Documentation

Datasheet
Ships from

Moscow
Наличие

4000 pcs In Stock
Estimated Price

$ 0.63

Buy MPSA13G

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MPSA13G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MPSA13G Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MPSA13G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW79238793
Category	BJT Transistor, BJT
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-226-3
Voltage Rating (DC)	30.0 V
Current Rating	500 mA
Output Voltage	30 V
Output Current	500 mA
Number of Positions	3 Position
Polarity	NPN
Power Dissipation	625 mW
Breakdown Voltage (Collector to Emitter)	30 V
Continuous Collector Current	0.5A
hFE Min	10000 @100mA, 5V
Input Power (Max)	625 mW
DC Current Gain (hFE)	10000
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Gain Bandwidth	125MHz (Min)
Power Dissipation (Max)	625 mW
Input Voltage	10 V
	expand all
Size-Length	5.2 mm
Size-Width	4.19 mm
Size-Height	5.33 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The MPSA13G is a NPN bipolar Darlington Transistor, designed for use in switching applications, such as print hammer, relay, solenoid and lamp drivers. Simplified circuit design and reduces component count.
