MSP430F2618TPMR ,Microcontroller, MCU IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

171 points

Part No

MSP430F2618TPMR
Manufacturer

TI
ChipWorker Part#

CW6209707
Category

Microcontroller, MCU IC
Package

LQFP-64
Description

16Bit Ultra-Low-Power MCU, 116KB Flash, 8KB RAM, 12Bit ADC, Dual DAC, 2 USCI, HW Mult, DMA 64-LQFP -40 to 105y
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 3.98

Buy MSP430F2618TPMR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MSP430F2618TPMR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MSP430F2618TPMR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MSP430F2618TPMR
Manufacturer	TI
ChipWorker Part#	CW6209707
Category	Microcontroller, MCU IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	64 Pin
Case/Package	LQFP-64
Frequency	16 MHz
Supply Voltage (DC)	1.80V (min)
Number of Positions	64 Position
Clock Speed	16.0 MHz
RAM Memory Size	8 KB
Number of Bits	16 Bit
FLASH Memory Size	116 KB
Number of UARTs	2 UART
Number of ADCs	1 ADC
FRAM Memory Size	0 B
Number of Inputs and Outputs	48 Input IO
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	1.8 V
	expand all
Operating Temperature	-40℃ ~ 105℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The MSP430F2618TPMR is a 16-bit ultra-low-power Mixed-signal Microcontroller features a powerful 16-bit RISC MSP430 CPU, 16-bit registers and constant generators that contribute to maximum code efficiency. The architecture combined with five low-power modes, is optimized to achieve extended battery life. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 1µs. The device configurations with two 16-bit timers, 12-bit A/D converter, a comparator, a hardware multiplier, four universal serial communication interface (USCI) modules and 48 general-purpose I/O pins. This device operates at a maximum frequency of 16MHz.
16-bit RISC architecture, 62.5ns instruction cycle time
3-channel internal DMA
12-bit ADC with internal reference, sample-and-hold and autoscan feature
Dual 12-bit DAC with synchronization
16-bit Timer_A with 3 Capture/Compare registers
16-bit Timer_B with 7 Capture/Compare registers
On-chip comparator
Enhanced UART supporting auto-baudrate detection
IrDA Encoder and decoder
Synchronous SPI
Supply voltage supervisor/monitor with programmable level detection
Brownout detector
Bootstrap loader
Serial on-board programming
No external programming voltage needed
Programmable code protection by security fuse
365µA at 1MHz, 2.2V Active mode (AM) power consumption
