NCP18XH103D03RB - muRata

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

NCP18XH103D03RB
Manufacturer

muRata
ChipWorker Part#

CW8904641
Category

Thermistor
Package

0603
Description

Thermistor NTC 10KΩ 1% 2Pin 0603 Surface Mount Solder Pad 3434K T/R
Documentation

Datasheet

NCP18XH103D03RB Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

NCP18XH103D03RB Specifications

Attribute	Attribute Value

Part Number	NCP18XH103D03RB
Manufacturer	muRata
ChipWorker Part#	CW8904641
Category	Thermistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package (SI)	1608
Case/Package	0603
Capacitance Tolerance	±0.5 %
Power Rating	0.1 W
Resistance	10000 Ω
Resistance Tolerance	±0.5 %
Input Power (Max)	100 mW
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
	expand all
Size-Length	1.6 mm
Size-Width	0.8 mm
Size-Height	0.8 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Simple to implement like a resistor this NCP18XH103D03RB thermistor developed by Murata will measure temperature. This part has a temperature range of -40 °C to 125 °C. It has 2 terminals. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep.
