OPA704PA ,Operational Amplifier, OP Amp IC - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

94 points

Part No

OPA704PA
Manufacturer

TI
ChipWorker Part#

CW89534614
Category

Operational Amplifier, OP Amp IC
Package

PDIP-8
Description

12V, CMOS, ail-to- ail I/O, Operational Amplifier 8-PDIP -40℃ to 85℃
Documentation

Datasheet
Ships from

Moscow
Наличие

303004 pcs In Stock
Estimated Price

$ 0.89

Buy OPA704PA

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

OPA704PA Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

OPA704PA Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	OPA704PA
Manufacturer	TI
ChipWorker Part#	CW89534614
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Current	160 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	70 dB
Input Offset Drift	4.00 µV/K
Bandwidth	3.00 MHz
Slew Rate	3.00 V/μs
Gain Bandwidth Product	3 MHz
Input Offset Voltage	160 µV
Input Bias Current	1 pA
Gain Bandwidth	3 MHz
Minimum CMRR Range	70 dB
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The OPA703 and OPA704 series op amps are optimized for applications requiring rail-to-rail input and output swing. Single, dual, and quad versions are offered in a variety of packages. While the quiescent current is less than 200µA per amplifier, the OPA703 still offers excellent dynamic performance (1MHz GBW and 0.6V/µs SR) and unity-gain stability. The OPA704 is optimized for gains of 5 or greater and provides 3MHz GBW and 3V/µs slew rate.
The OPA703 and OPA704 series are fully specified and guaranteed over the supply range of ±2V to ±6V. Input swing extends 300mV beyond the rail and the output swings to within 40mV of the rail.
The single versions (OPA703 and OPA704) are available in the MicroSIZE SOT23-5 and in the standard SO-8 surface mount, as well as the DIP-8 packages. Dual versions (OPA2703 and OPA2704) are available in the MSOP-8, SO-8, and DIP-8 packages. The quad OPA4703 and OPA4704 are available in the TSSOP-14 and SO-14 packages. All are specified for operation from –40°C to +85°C.
FEATURES
● RAIL-TO-RAIL INPUT AND OUTPUT
● WIDE SUPPLY RANGE:
Single Supply: 4V to 12V
Dual Supplies: ±2 to ±6
● LOW QUIESCENT CURRENT: 160µA
● FULL-SCALE CMRR: 90dB
● LOW OFFSET: 160µV
● HIGH SPEED:
OPA703: 1MHz, 0.6V/µs
OPA704: 3MHz, 3V/ µs
● MicroSIZE PACKAGES: SOT23-5, MSOP-8, TSSOP-14
● LOW INPUT BIAS CURRENT: 1pA
APPLICATIONS
● AUTOMOTIVE APPLICATIONS: Audio, Sensor Applications, Security Systems
● PORTABLE EQUIPMENT
● ACTIVE FILTERS
● TRANSDUCER AMPLIFIER
● TEST EQUIPMENT
● DATA ACQUISITION
