PMEG2010EH - NXP

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

PMEG2010EH
Manufacturer

NXP
ChipWorker Part#

CW35078507
Category

Schottky Diode
Package

SOD-123F
Description

Diode Schottky 20V 1A 2Pin SOD
Documentation

Datasheet

PMEG2010EH Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

PMEG2010EH Specifications

Attribute	Attribute Value

Part Number	PMEG2010EH
Manufacturer	NXP
ChipWorker Part#	CW35078507
Category	Schottky Diode
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SOD-123F
Number of Positions	2 Position
Forward Voltage	500 mV
Forward Current	1 A
Max Forward Surge Current (Ifsm)	9 A
Maximum Forward Voltage (Max)	500 mV
Forward Current (Max)	1 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature (Max)	150 ℃
	expand all
Size-Length	2.7 mm
Size-Width	1.7 mm
Size-Height	1.2 mm
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The PMEG2010EH is a very-low VF planar maximum efficiency general application (MEGA) Schottky Barrier Rectifier with an integrated guard ring for stress protection. It is encapsulated in small surface-mounted device (SMD) plastic package.
Very low forward-voltage
Low voltage rectification
High efficiency DC-to-DC conversion
Switch mode power supply
Reverse polarity protection
Low power consumption
