STM32F401CDU6 ,Microcontroller, MCU IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

98 points

Part No

STM32F401CDU6
Manufacturer

ST Microelectronics
ChipWorker Part#

CW16098941
Category

Microcontroller, MCU IC
Package

UFQFN-48
Description

MCU 32Bit STM32 ARM Cortex M4 RISC 384KB Flash 1.8V/2.5V/3.3V 48Pin UFQFPN EP Tray
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 8.26

Buy STM32F401CDU6

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STM32F401CDU6 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STM32F401CDU6 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STM32F401CDU6
Manufacturer	ST Microelectronics
ChipWorker Part#	CW16098941
Category	Microcontroller, MCU IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	48 Pin
Case/Package	UFQFN-48
Number of Positions	48 Position
Clock Speed	84 MHz
RAM Memory Size	96 KB
Number of Bits	32 Bit
Power Dissipation	625 mW
Number of ADCs	1 ADC
Number of Inputs and Outputs	36 Input IO
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	625 mW
Supply Voltage	1.7.3.6 VDC
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	1.7 V
	expand all
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Similar & Replacement Parts

Similar products

VISUAL TFT-LICENSE USB DONGLE

mikroElektronika

3 шт.

119.00 $/шт.

Product Description

The STM32F401CDU6 is a STM32 F4 series 32-bit Microcontroller based on the high-performance ARM Cortex-M4 RISC core operating at a frequency of up to 84MHz. Its Cortex-M4 core features a floating point unit (FPU) single precision which supports all ARM single precision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security. The device incorporate high-speed embedded memories (up to 384kB of Flash memory, up to 96kB of SRAM) and an extensive range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses and a 32-bit multi-AHB bus matrix. This device offer one 12-bit ADC, a low-power RTC, six general-purpose 16-bit timers including one PWM timer for motor control, two general-purpose 32-bit timers, as well as standard communication interfaces - up to three I²Cs, three SPIs, two I²Ss and three USARTs.
ARM 32-bit Cortex-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator™), MPU
105 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1) and DSP instructions
4 to 26MHz Crystal oscillator
Internal 16MHz factory-trimmed RC
32kHz Oscillator for RTC with calibration
16-stream DMA Controller with FIFOs and burst support
Serial wire debug (SWD) and JTAG interfaces
SDIO interface
USB 2.0 full speed device/host/OTG controller with on-chip PHY
CRC calculation unit
96-bit Unique ID
RTC - subsecond accuracy, hardware calendar
