STP17NK40ZFP - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

STP17NK40ZFP
Manufacturer

ST Microelectronics
ChipWorker Part#

CW11887593
Category

MOSFET, MOSFET Transistor
Package

TO-220-3
Description

TO-220FP N-CH 400V 15A
Documentation

Datasheet

STP17NK40ZFP Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STP17NK40ZFP Specifications

Attribute	Attribute Value

Part Number	STP17NK40ZFP
Manufacturer	ST Microelectronics
ChipWorker Part#	CW11887593
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	250 mΩ
Polarity	N-Channel
Power Dissipation	35 W
Threshold Voltage	3.75 V
Drain to Source Voltage (Vds)	400 V
Continuous Drain Current (Ids)	5.40 A
Rise Time	23 ns
Input Capacitance (Ciss)	1900pF @25V(Vds)
Input Power (Max)	35 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	35W (Tc)
	expand all
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	16.4 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The STP17NK40ZFP is a SuperMESH™ N-channel Zener-protected Power MOSFET obtained through an extreme optimization of ST"s well established strip-based PowerMESH™ layout. In addition to pushing ON-resistance significantly down, special care is taken to ensure a very good dV/dt capability for the most demanding applications.
0.23R RDS (ON)
Extremely high dV/dt capability
100% Avalanche tested
Gate charge minimized
Very low intrinsic capacitances
Very good manufacturing repeatability
-55 to 150°C Operating junction temperature range
