TC4425AVPA
Manufacturer

Microchip
ChipWorker Part#

CW14827604
Category

FET Driver
Package

PDIP-8
Description

3A 2Channel, BUF OR INV BASED MOSFET DRIVER, PDIP8, 0.3INCH, LEAD FREE, PLASTIC, DIP-8
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 2.73

Buy TC4425AVPA
