TMS320C25FNL ,DSP, Digital Signal Processor - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

85 points

Part No

TMS320C25FNL
Manufacturer

TI
ChipWorker Part#

CW8559292
Category

DSP, Digital Signal Processor
Package

PLCC-68
Description

DSP Fixed-Point 16Bit 40MHz 10MIPS 68Pin PLCC
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.66

Buy TMS320C25FNL

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TMS320C25FNL Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TMS320C25FNL Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TMS320C25FNL
Manufacturer	TI
ChipWorker Part#	CW8559292
Category	DSP, Digital Signal Processor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	68 Pin
Case/Package	PLCC-68
Frequency	40.96 MHz
Supply Voltage (DC)	4.75V (min)
Supply Current	100 mA
Number of Positions	68 Position
RAM Memory Size	1088 B
Number of Bits	16 Bit
Power Dissipation	2000 mW
Input Capacitance	15.0 pF
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	2000 mW
Supply Voltage	4.75V ~ 5.25V
	expand all
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	3A991.a.2

Similar & Replacement Parts

Similar products

Product Description

description
This data sheet provides complete design documentation for the second-generation devices of the TMS320 family. This facilitates the selection of the devices best suited for user applications by providing all specifications and special features for each TMS320 member. This data sheet is divided into four major sections: architecture, electrical specifications (NMOS and CMOS), timing diagrams, and mechanical data. In each of these sections, generic information is presented first, followed by specific device information. An index is provided for quick reference to specific information about a device.
• 80-ns Instruction Cycle Time
• 544 Words of On-Chip Data RAM
• 4K Words of On-Chip Secure Program EPROM (TMS320E25)
• 4K Words of On-Chip Program ROM (TMS320C25)
• 128K Words of Data/Program Space
• 32-Bit ALU/Accumulator
• 16 × 16-Bit Multiplier With a 32-Bit Product
• Block Moves for Data/Program Management
• Repeat Instructions for Efficient Use of Program Space
• Serial Port for Direct Codec Interface
• Synchronization Input for Synchronous Multiprocessor Configurations
• Wait States for Communication to Slow Off-Chip Memories/Peripherals
• On-Chip Timer for Control Operations
• Single 5-V Supply
• Packaging: 68-Pin PGA, PLCC, and CER-QUAD
• 68-to-28 Pin Conversion Adapter Socket for EPROM Programming
• Commercial and Military Versions Available
• NMOS Technology:
— TMS32020 . . . . . . . . . 200-ns cycle time
• CMOS Technology:
— TMS320C25 . . . . . . . . 100-ns cycle time
— TMS320E25 . . . . . . . . 100-ns cycle time
— TMS320C25-50 . . . . . . 80-ns cycle time
