UCC27322D ,FET Driver - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

154 points

Part No

UCC27322D
Manufacturer

TI
ChipWorker Part#

CW4541926
Category

FET Driver
Package

SOIC-8
Description

MOSFET DRVR 9A 1Out Lo Side Non-Inv 8Pin SOIC Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.34

Buy UCC27322D

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

UCC27322D Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

UCC27322D Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	UCC27322D
Manufacturer	TI
ChipWorker Part#	CW4541926
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	4.00V (min)
Rise/Fall Time	20 ns
Number of Outputs	1 Output
Output Voltage	150 mV
Output Current	9.00 A
Number of Positions	8 Position
Power Dissipation	650 mW
Rise Time	70 ns
Output Voltage (Max)	300 mV
Fall Time	30 ns
Fall Time (Max)	30 ns
Fall Time (Max)	70 ns
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	650 mW
Supply Voltage	4V ~ 15V
Supply Voltage (Max)	15 V
Supply Voltage (Min)	4 V
	expand all
Size-Length	4.9 mm
Size-Width	3.91 mm
Size-Height	1.58 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The UCC27322D is a single high speed low-side MOSFET Driver with enable function. It delivers 9A of peak drive current in an industry standard pin-out. This driver can drive the largest of MOSFETs for systems requiring extreme Miller current due to high dV/dt transitions. This eliminates additional external circuits and can replace multiple components to reduce space and design complexity. Two standard logic options are offered, non-inverting. Using a design that inherently minimizes shoot-through current, the outputs of these can provide high gate drive current where it is most needed at the Miller plateau region during the MOSFET switching transition. Unique hybrid output stage paralleling bipolar and MOSFET transistors (TrueDrive) allows efficient current delivery at low supply voltages. With this drive architecture, UCC3732x can be used in industry standard 6A, 9A and many 12A driver applications. Latch-up and ESD protection circuitries are also included.
