ZB5AG2 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ZB5AG2
Manufacturer

Schneider Electric
ChipWorker Part#

CW16652790
Category

Keylock Switch, Switch KeyLock
Description

Switch: rotary with key; 2Position; 22mm; black; Illumin: none
Documentation

Datasheet

ZB5AG2 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ZB5AG2 Specifications

Attribute	Attribute Value

Part Number	ZB5AG2
Manufacturer	Schneider Electric
ChipWorker Part#	CW16652790
Category	Keylock Switch, Switch KeyLock
Documentation	Datasheet
Actuator Type	Key
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-25 ℃
	expand all
Housing Material	Plastic
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	RoHS Compliant
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17

Product Description

The ZB5AG2 is a Ø22mm round Signalling Head for key selector switch. This head has plastic bezel and 2 positions 90° black key switch stay put operator. It is suitable for use with the harmony XALF and XB5 series switches.
Left key withdrawal position
Ronis 455 Type of keylock
Class II conforming to IEC 60536 protection
IP69K/IK06 Protection rating
NEMA 4X/13 Protection rating
1000000 Cycles mechanical durability
