1N4728A - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

1N4728A
Manufacturer

Fairchild
ChipWorker Part#

CW19891387
Category

Zener Diode, Zener
Package

DO-41-2
Description

1N4728 Series 1W 3.3V 100uA Through Hole Zener Diode - DO-41
Documentation

Datasheet

1N4728A Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

1N4728A Specifications

Attribute	Attribute Value

Part Number	1N4728A
Manufacturer	Fairchild
ChipWorker Part#	CW19891387
Category	Zener Diode, Zener
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	DO-41-2
Voltage Rating (DC)	3.30 V
Capacitance Tolerance	±5 %
Power Rating	1.00 W
Output Current	≤330 mA
Breakdown Voltage	3.30 V
Number of Positions	2 Position
Power Dissipation	1 W
Test Current	76 mA
Zener Voltage	3.3 V
Input Power (Max)	1 W
Operating Temperature (Max)	200 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	1000 mW
	expand all
Size-Length	5.21 mm
Size-Width	2.72 mm
Size-Height	2.72 mm
Material	Glass
Operating Temperature	-65℃ ~ 200℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The 1N4728A is a Zener Diode for general use and also suitable for many different applications. Color band denotes the cathode end polarity.
76mA Test current
100µA at 1V Maximum reverse leakage current
