AD5246 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD5246
Manufacturer	ADI
ChipWorker Part#	CW430810867
Documentation	Datasheet
	expand all
Product Lifecycle Status	Unknown

Similar & Replacement Parts

Similar products

Product Description

Product Details
The AD5246 provides a compact 2 mm × 2.1 mm packaged solution for 128-position adjustment applications. This device performs the same electronic adjustment function as a variable resistor. Available in four different end-to-end resistance values (5 kΩ, 10 kΩ, 50 kΩ, 100 kΩ), these low temperature coefficient devices are ideal for high accuracy and stability variable resistance adjustments.
The wiper settings are controllable through the I2C compatible digital interface, which can also be used to read back the present wiper register control word. The resistance between the wiper and either end point of the fixed resistor varies linearly with respect to the digital code transferred into the RDAC1 latch.
Operating from a 2.7 V to 5.5 V power supply and consuming 3 μA allows for usage in portable battery-operated applications.
**Applications**
* Mechanical potentiometer replacement in new designs
* Transducer adjustment of pressure, temperature, position, chemical, and optical sensors
* RF amplifier biasing
* Automotive electronics adjustment
* Gain control and offset adjustment
1The terms digital potentiometer, VR, and RDAC are used interchangeably in this document.
### Features and Benefits
128 Position
5kΩ, 10kΩ , 50kΩ , 100kΩ
End-to-End Resistance
Ultra-Compact SC70-6
(2 mm x 2.1 mm) Package
I2C Compatible Interface
Full Read/Write of Wiper Register
Power-on Preset to Midscale
Single Supply +2.7 V to +5.5 V
Low Temperature Coefficient
45 ppm/°C
Low Power, IDD=3 µA typical
Wide Operating Temperature
–40°C to +125°C
Evaluation Board Available
Available in lead-free (Pb-free) package
