AD7680ARM Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | AD7680ARM |
| Manufacturer | ADI |
| ChipWorker Part# | CW30594042 |
| Category | Analog to Digital, ADC IC |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | MSOP-8 |
| Digital Logic Level | SAR |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Bits | 16 Bit |
| Power Dissipation | 26.4 mW |
| Sample Rate | 100 ksps |
| Resolution (Bits) | 16.0 Bit |
| Number of ADCs | 1 ADC |
| Number of Inputs | 1 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 26.4 mW |
| Number of Input Channels | 1 Channel |
| Input Voltage | 5.5 V |
| expand all | |
| Size-Length | 3 mm |
| Size-Width | 3 mm |
| Size-Height | 0.85 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | End of Life |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| Mil-Spec | No |
| HK STC License | NLR |
Product Description
- GENERAL DESCRIPTION
- The AD7680 is a 16-bit, fast, low power, successive approximation ADC. The part operates from a single 2.5 V to 5.5 V power supply and features throughput rates up to 100 kSPS. The part contains a low noise, wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 7 MHz.
- FEATURES
- Fast throughput rate: 100 kSPS
- Specified for VDDof 2.5 V to 5.5 V
- Low power
- 3 mW typ at 100 kSPS with 2.5 V supply
- 3.9 mW typ at 100 kSPS with 3 V supply
- 16.7 mW typ at 100 kSPS with 5 V supply
- Wide input bandwidth
- 86 dB SNR at 10 kHz input frequency
- Flexible power/serial clock speed management
- No pipeline delays
- High speed serial interface
- SPI®/QSPI™/µWire/DSP compatible
- Standby mode: 0.5 µA max
- 6-Lead SOT-23 and 8-Lead MSOP packages
- APPLICATIONS
- Battery-powered systems:
- Personal digital assistants
- Medical instruments
- Mobile communications
- Instrumentation and control systems
- Remote data acquisition systems
- High speed modems
- Optical sensors
