ADM6315 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADM6315
Manufacturer	ADI
ChipWorker Part#	CW760484164
Documentation	Datasheet
Case/Package	SOT
	expand all
Product Lifecycle Status	Active

Similar & Replacement Parts

Product Description

Product Details
The ADM6315 is a reliable voltage-monitoring device that is suitable for use in most voltage-monitoring applications.
The ADM6315 is designed to monitor as little as a 1.8% degradation of a power supply voltage. The ADM6315 can monitor all voltages (at 100 mV increments) from 2.5 V to 5 V.
Included in this circuit is a debounced manual reset input. RESET can be activated using an ordinary switch (pulling MR low), a low input from another digital device, or a degradation of the supply voltage.
The manual reset function is very useful, especially if the circuit in which the ADM6315 is operating enters into a state that can be detected only by the user. Allowing the user to reset a system manually can reduce the damage or danger that could otherwise be caused by an out-of-control or locked-up system.
The ADM6315 is available in a cost- and space-efficient SOT-143 package.
**Applications**
Microprocessor systems
Controllers
Intelligent instruments
Automotive systems
Safety systems
Portable instruments
### Features and Benefits
Specified over temperature
Low power consumption (5 μA typical)
Precision voltage monitor of voltages from 2.5 V to 5 V at 100 mV increments
Reset assertion down to VCC > 1 V
Reset timeout periods: 1 ms, 20 ms, 140 ms, or 1120 ms (minimum)
Built-in manual reset
Pin compatible with the ADM811
Available in SOT-143 package
