CMX60D10 ,Solid State Relay - Crydom
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
140 points
-
Part NoCMX60D10
-
ManufacturerCrydom
-
ChipWorker Part#CW10171593
-
CategorySolid State Relay
-
PackageSIP-4
-
DescriptionRelay SSR 15mA 10V DC-IN 10A 60V DC-OUT 4Pin SIP
-
DocumentationDatasheet
-
Ships fromMoscow
-
НаличиеIn Stock
-
Estimated Price$ 52.07
Payment Methods and Delivery
{{ estimate }}
Buy CMX60D10
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
CMX60D10 Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
CMX60D10 Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | CMX60D10 | |
| Manufacturer | Crydom | |
| ChipWorker Part# | CW10171593 | |
| Category | Solid State Relay | |
| Documentation | Datasheet | |
| Mounting Style | Through Hole | |
| Number of Pins | 4 Pin | |
| Case/Package | SIP-4 | |
| Supply Voltage (DC) | 3.00V (min) | |
| Operating Voltage | 60.0V (max) | |
| Current Rating | 10 A | |
| Insulation Resistance | 1000 MΩ | |
| Capacitance | 15 pF | |
| Output Voltage | 0V ~ 60V | |
| Output Current | 10000 mA | |
| Contacts Type | SPST-NO | |
| Load Current | 10 A | |
| Input Current | 15 mA | |
| Isolation Voltage | 2500 v | |
| Input Impedance | 300 Ω | |
| Forward Current | 15 mA | |
| Input Voltage (Max) | 10 V | |
| Input Voltage (Min) | 3 V | |
| Output Voltage (Max) | 60 V | |
| Input Current (Min) | 15 mA | |
| Load Current (Max) | 10 Arms | |
| Load Current (Min) | 0 A | |
| Operating Temperature (Max) | 80 ℃ | |
| Operating Temperature (Min) | -30 ℃ | |
| Voltage Rating | 60 VDC | |
| Operating Voltage (Min) | 0 VDC | |
| Operating Voltage (Max) | 60 VDC | |
| Input Voltage | 3VDC ~ 10VDC | |
| expand all | ||
| Size-Length | 43.1 mm | |
| Size-Width | 7.6 mm | |
| Size-Height | 25.4 mm | |
| Operating Temperature | -30℃ ~ 80℃ | |
| Product Lifecycle Status | Active | |
| Packaging | Bulk | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance | No SVHC | |
| HTS Code | 8536410060 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- The CMX60D10 is a 1-phase Solid State Relay with thermally conductive epoxy encapsulation, SPST-NO contact, DC switch mode and through hole terminals. This CMX-series PCB mount relay features low on-state impedance.
- DC control
- MOSFET Output
- 0.18VDC Maximum on-state voltage drop
- 300R Nominal input impedance
- 2500Vrms Dielectric strength
- 1ms Turn-on and 300µsec turn-off maximum time
- -30 to 80°C Ambient operating temperature range
- Disconnect all power before installing or working with this equipment. Risk of material damage and hot enclosure.
