CSD85312Q3E ,MOSFET, MOSFET Transistor - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

64 points

Part No

CSD85312Q3E
Manufacturer

TI
ChipWorker Part#

CW41625345
Category

MOSFET, MOSFET Transistor
Package

PowerVDFN-8
Description

VSON N-CH 20V 39A
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.73

Buy CSD85312Q3E

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

CSD85312Q3E Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

CSD85312Q3E Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	CSD85312Q3E
Manufacturer	TI
ChipWorker Part#	CW41625345
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	PowerVDFN-8
Drain to Source Resistance (on) (Rds)	0.0103 Ω
Polarity	Dual N-Channel
Power Dissipation	2.5 W
Threshold Voltage	1.1 V
Drain to Source Voltage (Vds)	20 V
Continuous Drain Current (Ids)	39A
Rise Time	27 ns
Input Capacitance (Ciss)	2390pF @10V(Vds)
Input Power (Max)	2.5 W
Fall Time	6 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2500 mW
	expand all
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The CSD85312Q3E is a 20 V common-source, dual N-channel device designed for adaptor or USB input protection. This SON 3.3 × 3.3 mm device has low drain to drain on-resistance that minimizes losses and offers low component count for space constrained multi-cell battery charging applications.
