Part No

LMZ10503TZ-ADJ/NOPB
Manufacturer

TI
ChipWorker Part#

CW17502039
Category

DC to DC Converter
Package

TO-PMOD-7
Description

DC-DC POL Converter, Adjustable, Buck, 1MHz, 800mV to 5V out, 3A, TO-PMOD-7
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 22.21

Buy LMZ10503TZ-ADJ/NOPB

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LMZ10503TZ-ADJ/NOPB Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LMZ10503TZ-ADJ/NOPB Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LMZ10503TZ-ADJ/NOPB
Manufacturer	TI
ChipWorker Part#	CW17502039
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	7 Pin
Case/Package	TO-PMOD-7
Power Rating	15 W
Number of Outputs	1 Output
Output Voltage	0.8V ~ 5V
Output Current	3 A
Number of Positions	7 Position
Quiescent Current	1.7 mA
Number of Regulated Outputs	1 Output
Switching Frequency	1 MHz
Topology	Buck
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.95 V
Output Voltage (Max)	5 V
Output Voltage (Min)	800 mV
Output Current (Max)	3 A
Input Power (Max)	15 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	2.95V ~ 5.5V
	expand all
Size-Length	10.2 mm
Size-Width	13.8 mm
Size-Height	4.57 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The LMZ10503 SIMPLE SWITCHER power module is a complete, easy-to-use DC-DC solution capable of driving up to a 3-A load with exceptional power conversion efficiency, output voltage accuracy, line and load regulation. The LMZ10503 is available in an innovative package that enhances thermal performance and allows for hand or machine soldering.
The LMZ10503 can accept an input voltage rail between 2.95 V and 5.5 V and can deliver an adjustable and highly accurate output voltage as low as 0.8 V. One megahertz fixed-frequency PWM switching provides a predictable EMI characteristic. Two external compensation components can be adjusted to set the fastest response time, while allowing the option to use ceramic and/or electrolytic output capacitors. Externally programmable soft-start capacitor facilitates controlled startup. The LMZ10503 is a reliable and robust solution with the following features: lossless cycle-by-cycle peak current limit to protect for over current or short-circuit fault, thermal shutdown, input undervoltage lockout, and prebiased start-up.
