MA160012 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MA160012
Manufacturer

Microchip
ChipWorker Part#

CW48414303
Category

Microprocessor Development Kit
Package

Board
Description

PIC16F1937 PIC16 100Pin PIM
Documentation

Datasheet

MA160012 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MA160012 Specifications

Attribute	Attribute Value

Part Number	MA160012
Manufacturer	Microchip
ChipWorker Part#	CW48414303
Category	Microprocessor Development Kit
Documentation	Datasheet
Number of Pins	100 Pin
Case/Package	Board
Core Architecture	PIC
Core Sub-Architecture	PIC16
	expand all
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A991.a.2

Product Description

The PIC16F1937 Plug-in Module (PIM) is an accessory to the PICDEM PIC18 Explorer Board that allows users to experiment easily with the PIC16F193x/194x family of microcontrollers.
PIC16F1937 Plug-in module for PICDEM PIC18 explorer board
Enhanced Mid-range core with 49 Instruction, 16 stack levels
Flash program memory with self read/write capability
96 LCD segment drive support
Internal 32MHz oscillator, 25mA source/sink current i/o
Integrated capacitive mTouch sensing module
Integrated temperature indicator
MI2C, SPI, EUSART w/auto baud
3 ECCP & 2 CCP (Enhanced/Capture Compare PWM)
14 channel 10b ADC with voltage reference

expand all
