Part No

PTR08100WVD
Manufacturer

TI
ChipWorker Part#

CW9380345
Category

DC to DC Converter, DC/DC Converter
Package

SIP-5
Description

TEXAS INSTRUMENTS PTR08100WVD Non Isolated Board Mount DC-DC Converter, SIP, 55W, 600mV, 5.5V, 10A, 4.5V
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 17.26

Buy PTR08100WVD

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

PTR08100WVD Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

PTR08100WVD Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	PTR08100WVD
Manufacturer	TI
ChipWorker Part#	CW9380345
Category	DC to DC Converter, DC/DC Converter
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	SIP-5
Frequency	300 kHz
Supply Voltage (DC)	12.0 V
Power Rating	55 W
Number of Outputs	1 Output
Input Voltage (DC)	4.50V ~ 14.0V
Output Voltage	0.6V ~ 5.5V
Output Current	10 A
Number of Regulated Outputs	1 Output
Topology	Buck
Input Voltage (Max)	14 V
Input Voltage (Min)	4.5 V
Input Voltage (DC Max)	14 V
Input Voltage (DC Min)	4.5 v
Output Voltage (Max)	5.5 V
Output Voltage (Min)	600 mV
Output Current (Max)	10 A
Input Power (Max)	55 W
Input Power (Max)	55 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	4.5V ~ 14V
	expand all
Size-Length	13.51 mm
Size-Width	11.43 mm
Size-Height	11.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The PTR08100WVD is a Non-isolated Adjustable Switching Regulator with wide output voltage and wide input voltage range. The 10A converter provides output current at a much higher efficiency and with much less power dissipation, thereby eliminating the need for a heat sink. Using state-of-the-art switched-mode power-conversion technology, the output voltage can be stepped-down. The output voltage can be adjusted to any voltage over the range, 0.6 to 5.5V, using a single external resistor. It is well suited to a wide variety of general-purpose applications.
