STG3157CTR ,Analog Switch Ic, Analog Switch Multiplexer - ST Microelectronics
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
89 points
-
Part NoSTG3157CTR
-
ManufacturerST Microelectronics
-
ChipWorker Part#CW14356444
-
CategoryAnalog Switch Ic, Analog Switch Multiplexer
-
PackageSOT-323-6
-
DescriptionSTMICROELECTRONICS STG3157CTR Analog Switch, Single Channel, SPDT, 1Channels, 15Ω, 1.65V to 5.5V, SOT-323, 6Pins
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие20 pcs In Stock
-
Estimated Price$ 0.18
