TPS51225CRUKR ,Voltage Regulator - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

128 points

Part No

TPS51225CRUKR
Manufacturer

TI
ChipWorker Part#

CW6477964
Category

Voltage Regulator
Package

WQFN-20
Description

DC-DC Cntrlr Dual-OUT Step Down 360kHz/430kHz 20Pin WQFN EP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

25189 pcs In Stock
Estimated Price

$ 2.61

Buy TPS51225CRUKR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TPS51225CRUKR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TPS51225CRUKR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TPS51225CRUKR
Manufacturer	TI
ChipWorker Part#	CW6477964
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	WQFN-20
Number of Outputs	2 Output
Quiescent Current	900 µA
Number of Regulated Outputs	2 Output
Switching Frequency	300kHz, 355kHz
Topology	Buck
Input Voltage (Max)	24 V
Input Voltage (Min)	5.5 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	5.5V ~ 24V
Input Voltage	5.5V ~ 24V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The TPS51225/B/C is a cost-effective, dual-synchronous buck controller targeted for notebook
system-power supply solutions. It provides 5-V and 3.3-V LDOs and requires few external components. The 260-kHz VCLK output can be used to drive an external charge pump, generating gate drive voltage for the load switches without reducing the main converter efficiency. The TPS51225/B/C supports high efficiency, fast transient response and provides a combined power-good signal. Adaptive on-time, D-CAP™ control provides convenient and efficient operation. The device operates with supply input voltage ranging from 5.5 V to 24 V and supports output voltages of 5.0 V and 3.3 V. The TPS51225/B/C is available in a 20-pin, 3 mm × 3 mm, QFN package and is specified from –40°C to 85°C.
FEATURES
• Input Voltage Range: 5.5 V to 24 V
• Output Voltages: 5 V and 3.3 V (Adjustable Range ±10%)
• Built-in, 100-mA, 5-V and 3.3-V LDOs
• Clock Output for Charge-Pump
• ±1% Reference Accuracy
• Adaptive On-time D-CAP™ Mode Control Architecture with 300kHz/355kHz Frequency Setting
• Auto-skip Light Load Operation (TPS51225/C)
• OOA Light Load Operation (TPS51225B)
• Internal 0.8-ms Voltage Servo Soft-Start
• Low-Side RDS(on) Current Sensing Scheme with 4500 ppm/°C Temperature Coefficient
• Built-in Output Discharge Function
• Separate Enable Input for Switchers(TPS51225/B/C)
• Dedicated OC Setting Terminals
• Power Good Indicator
• OVP/UVP/OCP Protection
• Non-latch UVLO/OTP Protection
• 20-Pin, 3 mm × 3 mm, QFN (RUK)
APPLICATIONS
• Notebook Computers
• Netbook, Tablet Computers

expand all
