TS272CN ,Operational Amplifier, OP Amp IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

80 points

Part No

TS272CN
Manufacturer

ST Microelectronics
ChipWorker Part#

CW69177600
Category

Operational Amplifier, OP Amp IC
Package

DIP-8
Description

STMICROELECTRONICS TS272CN Operational Amplifier, Dual, 2 Amplifier, 3.5MHz, 5.5V/µs, 3V to 16V, DIP, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

733617 pcs In Stock
Estimated Price

$ 0.16

Buy TS272CN

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TS272CN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TS272CN Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TS272CN
Manufacturer	ST Microelectronics
ChipWorker Part#	CW69177600
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	16.0V (max)
Operating Voltage	3V ~ 16V
Supply Current	1 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Bandwidth	3.5 MHz
Slew Rate	5.50 V/μs
Gain Bandwidth Product	3.5 MHz
Input Offset Voltage	1.1 mV
Input Bias Current	1 pA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Gain Bandwidth	3.5 MHz
Minimum CMRR Range	65 dB
Supply Voltage	3V ~ 16V
	expand all
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The TS272 devices are low cost, dual operational amplifiers designed to operate with single or dual supplies. These operational amplifiers use the ST silicon gate CMOS process allowing an excellent consumption-speed ratio. These series are ideally suited for low consumption applications.
Three power consumptions are available allowing to have always the best consumption-speed ratio:
❑ ICC = 10µA/amp.: TS27L2 (very low power)
❑ ICC = 150µA/amp.: TS27M2 (low power)
❑ ICC = 1mA/amp.: TS272 (standard)
These CMOS amplifiers offer very high input impedance and extremely low input currents. The major advantage versus JFET devices is the very low input currents drift with temperature (see figure 2).
■ OUTPUT VOLTAGE CAN SWING TO GROUND
■ EXCELLENT PHASE MARGIN ON CAPACITIVE LOADS
■ GAIN BANDWIDTH PRODUCT: 3.5MHz
■ STABLE AND LOW OFFSET VOLTAGE
■ THREE INPUT OFFSET VOLTAGE SELECTIONS
