25C080 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

25C080
Manufacturer

Microchip
ChipWorker Part#

CW544049437
RoHS

Lead free / RoHS Compliant
Description

8K/16K 5V SPI Bus Serial EEPROM
Documentation

Datasheet

25C080 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

25C080 Specifications

Attribute	Attribute Value

Part Number	25C080
Manufacturer	Microchip
ChipWorker Part#	CW544049437
Documentation	Datasheet
	expand all
RoHS	RoHS Compliant

Product Description

Description:
The Microchip Technology Inc. 25AA080/25LC080/25C080 (25XX080) are 8 Kbit Serial Electrically Erasable PROMs. The memory is accessed via a simple Serial Peripheral Interface (SPI) compatible serial bus. The bus signals required are a clock input (SCK) plus separate data in (SI) and data out (SO) lines. Access to the device is controlled through a Chip Select (CS) input.
Features:
• Low-power CMOS technology:
- Write current: 3 mA maximum
- Read current: 500 A typical
- Standby current: 500 nA typical
• 1024 x 8-bit organization
• 16 byte page
• Write cycle time: 5 ms max.
• Self-timed erase and write cycles
• Block write protection:
- Protect none, 1/4, 1/2 or all of array
• Built-in write protection:
- Power-on/off data protection circuitry
- Write enable latch
- Write-protect pin
• Sequential read
• High reliability:
- Endurance: 1 M cycles
- Data retention: > 200 years
- ESD protection: > 4000V
• 8-pin PDIP and SOIC (150 mil)
• Temperature ranges supported:
- Industrial (I): -40C to +85C
- Automotive (E) (25C080): -40°C to +125°C
