Part No

ISO7640FMDW
Manufacturer

TI
ChipWorker Part#

CW15536157
Category

Interface Isolator, Digital Isolator
Package

SOIC-16
Description

TEXAS INSTRUMENTS ISO7640FMDW Digital Isolator, Quad, 4Channel, 8.5ns, 2.7V, 5.5V, SOIC, 16Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

29 pcs In Stock
Estimated Price

$ 11.4

Buy ISO7640FMDW

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ISO7640FMDW Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ISO7640FMDW Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ISO7640FMDW
Manufacturer	TI
ChipWorker Part#	CW15536157
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	2.70 V, 3.30 V, 5.00 V
Rise/Fall Time	1.6ns, 1ns
Supply Current	2.00 mA
Number of Channels	4 Channel
Number of Positions	16 Position
Power Dissipation	399 mW
Data Rate	150 Mbps
Rise Time	2.3 ns
Isolation Voltage	4243 Vrms
Thermal Shutdown	No
Input Current (Min)	10 μA
Fall Time (Max)	1.3 ns
Fall Time (Max)	2 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	399 mW
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	10.5 mm
Size-Width	7.6 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The ISO7640FMDW is a quad channel 150Mbps Digital Isolator provides galvanic isolation up to 6kVPK for 1 minute per UL and VDE. This device is certified up to 5kVRMS Reinforced isolation at a working voltage of 400VRMS per end equipment standards EN/UL/CSA 60950-1 and 61010-1. ISO7640F and ISO7641F are quad-channel isolators, ISO7640F has four forward and one reverse-direction channels. Suffix F indicates that output defaults to low-state in fail-safe conditions. M-grade device is high-speed isolator capable of 150Mbps data rate with fast propagation delays. Each isolation channel has a logic input and output buffer separated by a silicon dioxide (SiO2) insulation barrier. Used in conjunction with isolated power supplies, these devices prevent noise currents on a data bus or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. The device has TTL input thresholds.
