STM32F303CCT6 - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

STM32F303CCT6
Manufacturer

ST Microelectronics
ChipWorker Part#

CW460966
Category

Microcontroller, MCU IC
Package

LQFP-48
Description

MCU 32Bit ARM Cortex M4 RISC 256KB Flash 2.5V/3.3V 48Pin LQFP Tray
Documentation

Datasheet

STM32F303CCT6 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STM32F303CCT6 Specifications

Attribute	Attribute Value

Part Number	STM32F303CCT6
Manufacturer	ST Microelectronics
ChipWorker Part#	CW460966
Category	Microcontroller, MCU IC
Documentation	Datasheet
Number of Pins	48 Pin
Case/Package	LQFP-48
Frequency	72 MHz
Supply Voltage (DC)	2.00V (min)
Operating Voltage	2V ~ 3.6V
Number of Positions	48 Position
Clock Speed	72.0 MHz
RAM Memory Size	40 KB
Number of Bits	32 Bit
FLASH Memory Size	256 KB
Number of ADCs	4 ADC
Number of Inputs and Outputs	20 Input IO
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	2 DAC
Supply Voltage	2V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2 V
	expand all
Size-Length	10 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A991A2

Product Description

The STM32F303CCT6 is a 32-bit 256kB flash ARM®Cortex® -M4 Microcontroller Unit offers digital signal processing (DSP) and floating point unit (FPU). It offers up to four fast 12-bit ADCs, seven comparators and four operational amplifiers, up to two DAC channels, a low-power RTC and up to five general-purpose 16-bit timers, one general-purpose 32-bit timer and two timers dedicated to motor control. It also features standard and advanced communication interfaces up to two I²Cs, up to three SPIs and three USARTs, up to two UARTs, CAN and USB. To achieve audio class accuracy, the I²S peripherals can be clocked via an external PLL. It incorporates high-speed embedded memories and an extensive range of enhanced I/Os and peripherals connected to two APB buses.
CRC calculation unit
Reset and power management - Power-ON/power DOWN reset (POR/PDR)
Programmable voltage detector
Low-power - Sleep, stop and standby
VBAT supply for RTC and backup registers
Interconnect matrix
Calendar RTC with alarm, periodic wakeup from stop/standby
Serial wire debug, Cortex®-M4 with FPU ETM, JTAG
96-bit Unique ID
ESD sensitive device, take proper precaution while handling the device.
