AD9761ARSZ ,Digital to Analog, DAC IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

188 points

Part No

AD9761ARSZ
Manufacturer

ADI
ChipWorker Part#

CW1218389
Category

Digital to Analog, DAC IC
Package

SSOP-28
Description

ANALOG DEVICES AD9761ARSZ Digital to Analog Converter, 10Bit, 40MSPS, Parallel, 2.7V to 5.5V, 3V to 5.5V, SSOP, 28Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

283187 pcs In Stock
Estimated Price

$ 3.12

Buy AD9761ARSZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD9761ARSZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD9761ARSZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD9761ARSZ
Manufacturer	ADI
ChipWorker Part#	CW1218389
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	SSOP-28
Number of Outputs	2 Output
Supply Current	26 mA
Number of Channels	2 Channel
Number of Positions	28 Position
Number of Bits	10 Bit
Power Dissipation	250 mW
Sample Rate	40 Msps
Resolution (Bits)	10.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	250 mW
Number of DACs	2 DAC
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Height	1.75 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The AD9761ARSZ is a complete 2-channel high speed 10-bit CMOS Digital-to-analog Converter (DAC) has been developed specifically for use in wide bandwidth communication applications where digital I and Q information is being processed during transmit operations. The AD9761 supports a 20MSPS per channel input data rate that is then interpolated by 2x up to 40MSPS before simultaneously updating DAC. The interleaved I and Q input data stream is presented to the digital interface circuitry, which consists of I and Q latches as well as some additional control logic. The data is de-interleaved back into its original I and Q data. An on-chip state machine ensures the proper pairing of I and Q data. The data output from each latch is then processed by a 2x digital interpolation filter that eases the reconstruction filter requirements. The interpolated output of each filter serves as the input of its respective 10-bit DAC.
Excellent gain and offset matching
Differential nonlinearity error - 0.5LSB
Signal-to-noise and distortion ratio - 59dB
Spurious-free dynamic range - 71dB
On-chip reference
